The Xtreme series amplifiers are new to the EDGE rangeand feature Class D topology but use a full bridge method of power delivery. This is more efficient method of converting DC power from your battery to AC output for your speakers. Full bridge technoology allows us to generate large power in a tiny footprint. The custom tooled heatsink was designed with over engineered fins for excellent heat dissertation ensuring the amp works well and cools correctly.
Features:
Built in active crossovers
Ultran efficient Class D topology
Wideband frequency up to 20kHz
Full bridge technology
Compact footprint
Bass boost circuit
| Artikelnummer | EDX1800.2FD |
|---|---|
| Merk | EDGE |
| Aantal kanalen | 2-Kanaals |
| MAX vermogen | 7200W |
| RMS Vermogen 2x 4Ω | 850W |
| RMS Vermogen 2x 2Ω | 1250W |
| RMS Vermogen 2x 1Ω | 1800W |
| RMS Vermogen 1x 4Ω | 2500W |
| RMS Vermogen 1x 2Ω | 3600W |
| Low Pass | 50 - 1500 Hz |
| High Pass | 15 - 1000 Hz |
| Bass Boost | 0-12dB (variabel) |
| Afmetingen (LxBxH) | 232 x 264 x 63 mm |
| Bass Remote Controller | Ja, inclusief |
| RCA Output | Nee |
| High Input | Nee |
| Klasse | D |
